B800-1502 (B-Series Light-Duty Foot Switch)

$ 23.10

SKU: B800-1502 Category:

Description

The B800-1502 foot switch offers a small footprint in a long-lasting switch that’s perfect for any application requiring a smaller size. The unit features a compact steel housing designed to minimize the footprint and a traction pad on the base. Features a 15-amp, 125/250 VAC-rated switch with an 8-foot cable and 3 leads to be connected to your device: one ground, one common, and one wired normally open. This is a momentary foot switch, which means that it turns your product on when your foot is on the pedal, and turns it off when you release your foot from the pedal. You will have to hard-wire this to your equipment, so consult an electrical or knowledgeable person for proper wiring advice if needed (or see B850-1501 for the 3-pronged piggyback plug version). Enclosure rating: UL/CSA/NEMA Type 1 and IEC 60529 IP20. For indoor use in dry environments. Certified to CSA and UL standards. Size: 3.0″ L x 2.6″ W x 1.2″ H; 0.5 pounds without cable. Replaces 491-SC36. One year warranty on parts and labor. Made in USA.
  • Mounting: traction pad
  • Switch Rating: 15 A, ½ HP, 125/250 VAC; 0.1 A, 125 VDC
  • Circuit: SPDT wired N.O.
  • Cable: 8-ft cable with leads
  • Info Sheet
  • Exterior Dimensions

Additional information

Weight 1.6 lbs
Dimensions 9 × 5 × 3 in
